HP Thunderbolt 4 180W G6 Dock 9X481UT

HP Thunderbolt 4 180W G6 Dock 9X481UT

External Ports Location 01

Front

External Ports 01

1 USB Type-C® 10Gbps signaling rate (up to 15 W USB Power Delivery)

External Ports Location 02

Right side

External Ports 02

1 USB Type-A 10Gbps signaling rate (charging); 1 nano security lock slot; 1 USB Type-C® 10Gbps signaling rate (up to 15 W USB Power Delivery)

External Ports Location 03

Left side

External Ports 03

2 USB Type-A 10Gbps signaling rate (charging)

External Ports Location 04

Rear

External Ports 04

1 Thunderbolt™ 4 with USB Type-C® 40Gbps signaling rate; 1 USB Type-C® 10Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4); 2 USB Type-A 5Gbps signaling rate (charging); 1 HDMI 2.1; 2 DisplayPort™ 1.4; 1 RJ-45 (2.5 GbE)

Power supply

230 W external power adapter

Connection Type

Thunderbolt™ 4

Manageability features

HP CMSL; Disconnected Firmware updates; eTag; PXE Boot; Wake on LAN (from the Off, Sleep or Hibernation states); MAC address pass-through (from the On, Off, Sleep or Hibernation states); LAN/WLAN switching; Disable LAN; Event messaging; Intel® vPro® Technology (wired)

Cable length

3.2 ft

Power to Host

Up to 180 W via Thunderbolt™ 4 (both HP and non-HP host devices that support Power Delivery 3.1)

Power Delivery (PD) Profiles

12V/5A; 15V/5A; 20V/5A; 5V/3A; 9V/3A

Display Support

Up to 3 external displays and 1 PC display or up to 4 external displays

Power Button Type

Mechanical power button with RGB LED indicator to power or wake host system

Compatibility

Tested and supported on select HP commercial PCs. For HP notebook compatibility please visit - https://pcb.inc.hp.com/webapp/#!/us-en and search by notebook. Tested and supported on select 3rd party PCs. Contact your local sales representative to learn more.

Compatible operating systems

Windows 10; Windows 11; macOS; Linux; ThinPro; ChromeOS

Minimum system requirements

USB Type-C® (USB Power Delivery, Alt Mode DisplayPort™); Thunderbolt™ 4 port

Dimensions (W X D X H)

4.76 x 4.76 x 1.95 in

Weight

1.7 lb

Warranty

HP three-year limited warranty

What's in the box

HP Thunderbolt 4 Ultra 180W G6 Dock; 230 W power adapter; Thunderbolt™ 4 cable (1 m); Power cord; Product notice; Warranty card
