AMD RYZEN 5 9600X Box AM5 (100-100001405WOF) (AMDRYZ5-9600X)
48437
Μεταφορικά
Τρόποι Πληρωμής
AMD CPU RYZEN 5 9600X, 6C/12T, 3.9-5.4GHz, CACHE 6MB L2+32MB L3, SOCKET AM5, BOX, 3YW.
Περιγραφή
| General Specifications | |
| Platform | Desktop |
| Market Segment | Enthusiast Desktop |
| Product Family | AMD Ryzen™ Processors |
| Product Line | AMD Ryzen™ 5 Desktop Processors |
| AMD PRO Technologies | No |
| Former Codename | "Granite Ridge AM5" |
| Architecture | "Zen 5" |
| # of CPU Cores | 6 |
| Multithreading (SMT) | Yes |
| # of Threads | 12 |
| Max. Boost Clock | Up to 5.4GHz |
| Base Clock | 3.9GHz |
| L1 Cache | 384KB |
| L2 Cache | 6MB |
| L3 Cache | 32MB |
| Default TDP | 65W |
| Processor Technology for CPU Cores | TSMC 4nm FinFET |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| Package Die Count | 2 |
| Unlocked for Overclocking | Yes |
| AMD EXPO™ Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen™ Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets | A620 X670E X670 B650E B650 X870E X870 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
| >td >Not Included | |
| Max. Operating Temperature (Tjmax) | 95°C |
| OS Support | Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit |
| Connectivity | |
| USB Type-C® Support | Yes |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native USB 2.0 (480Mbps) Ports | 1 |
| Native SATA Ports | 0 |
| PCI Express® Version | PCIe® 5.0 |
| Native PCIe® Lanes (Total/Usable) | 28/24 |
| Additional Usable PCIe Lanes from Motherboard | X870E: 8x Gen4 X870: 4x Gen4 X670E: 12x Gen4 X670: 12x Gen4 B650E: 8x Gen4 B650: 8x Gen4 |
| NVMe Support | Boot , RAID0 , RAID1 , RAID5 , RAID10 |
| Memory Channels | 2 |
| Max. Memory | 192GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed | 2x1R: 5600 MT/s 2x2R: 5600 MT/s 4x1R: 3600 MT/s 4x2R: 3600 MT/s |
| ECC Support | Yes (Requires mobo support) |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | AMD Radeon™ Graphics |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 MHz |
| GPU Base | 400 MHz |
| USB Type-C® DisplayPort™ Alternate Mode | Yes |
| Key Features | |
| Supported Technologies | AMD EXPO™ Technology AMD Ryzen™ Technologies |
Τεχνικά Χαρακτηριστικά
| Κατασκευαστής | AMD |
| Μοντέλο | Ryzen 5 9600X |
| Part Number | 100-100001405WOF |
| Κατηγορία | Επεξεργαστές |
| Socket | AM5 |
| Σειρά Επεξεργαστή | AMD Ryzen 5 |
| Συχνότητα Λειτουργίας | 3.90 GHz 5.40 GHz Turbo |
| Οικογένεια | Ryzen |
| Αριθμός Πυρήνων | 6 cores 12 threads |
| Μνήμη Cache | 38MB |
| TDP | 65W |
| Ενσωματωμένα Γραφικά | Radeon Graphics |
| Εγγύηση | 3 Έτη |
